Electrochemical Performance Parameters | |
Current Range | 0-150 A (Adjustable) |
Current Accuracy | ±0.1% FS |
Voltage Range | 0 - 50 V(Adjustable) |
Voltage Accuracy | ±0.1% FS |
Polarization Voltage | Adjustable for dynamic current scanning |
Current Response Time | ≤1 ms |
Voltage Response Time | ≤1 ms |
Water Control | |
Water Tank Capacity | 20L |
Circulation Water | 1.2-2L five stage adjustment |
Heating Temperature Range Of Circulating Water | Room temperature -80 ° C |
Heating Temperature Control Accuracy | ±2°C |
Cooling System | Natural cooling |
Gas Production Monitoring | |
Hydrogen production detection | Digital mass flow meter, 1% SF high-precision |
Control and Data Collection | |
Control Mode | Manual back pressure manual/automatic adjustment of power supply |
Data Acquisition Software | Real time current, voltage, and power curves |
Data Record | Multi channel data recording with a minimum interval of 1 ms |
Ion concentration filtration and monitoring | |
Circulating water ion concentration monitoring, monitoring range 0-20 μ S/cm, monitoring accuracy ± 1F · S. | |
Circulating water ion filtration, ion conductivity after filtration ＜ 5 μ The maximum filtration flow rate of S/cm is less than 5L/min, the medium material is ion exchange resin, and the operating temperature is -40~90 ℃. | |
