Hydrogen Production | 20Nm3/h |
Working Pressure | ≤1.6MPa |
Number Of Compartments | 96 PCS |
Effective Electrode Plate Diameter | 378mm |
Current Density | ≤5000A |
DC Voltage | ≤196V |
DC Current | ≤500A |
Overall Dimensions (L * D * H) | 1200*569*579mm（Based On Actual Situation） |
Weight | 750KG |
2、The main components of the electrolyzer (Main parts)：
Positive Terminal Pressure Plate | 1 PCS |
Negative Terminal Pressure Plate | 1 PCS |
Bipolar(Carbon Steel Nickel Plated) | 95 PCS |
N6 Support Network | 192 PCS |
Black Gasket | 96 PCS |
Tension Bolt | 16 PCS |
Tightening Nut | 32 PCS |
Insulating Pad | 32 PCS |
Insulating Sleeve | 16 PCS |
Stainless Steel Nut Gasket | 64 PCS |
Belleville Spring | 1560 PCS |
3、Main interfaces of electrolyzer:
Hydrogen Outlet： | 25MM Union |
Oxygen Outlet： | 25MM Union |
Oxygen Iye Inlet： | 25MM Union |
Hydrogen Iye Inlet： | 25MM Union |
